#### I have a sample on hand, how do i know what size?

Measure the outer diameter of the cylinder, then measure the length between pin holes (with the center rod pushed all the way in to the cylinder) to get the approximate push/pull length, then measure the diameter of the push/pull rod. If you have a pin in the attachment points, measure the diameter of the pin (usually 3/4 inch or 1 inch diameter).This will give you a reading of something like a cylinder (3 inches inside) for 3 1/4 inches outside, type of attachment points, size of pins, and overall push/pull length (50 inches). The cylinder may be a 3 inch cylinder with 1 inch pins and be 50 inches overall, and maybe then you can choose different lifting, pulling, or pushing weights like 5000 pounds, etc. This is only an example of cylinder measurements; they can be bigger, smaller, shorter, have a lower weight capacity, etc.I hope this helps you out.

#### How do I know what size to order?

Four ways. 1) Send us the drawing if you have one; 2) Measure the size of the sample if you have one; 3) Send us a sample if possible; 4) Look closely at the chart; the retracted length must match what you have; the extended length may vary a little. The rod size is the shaft that moves in and out; you can see and measure that; the bore is the inside of the main housing that you can’t see or measure unless it’s apart. Order mainly by length, not bore and stroke, then get the rod size as close as you can, and the bore size should work out right.

#### What is the difference between double acting and single acting cylinders?

Double-acting: have a port at each end, supplied with hydraulic fluid for both the retraction and extension.Single-acting: hydraulic fluid enters through a port at one end of the cylinder, which extends the rod by means of an area difference. An external force or gravity returns the piston rod.

#### Could we get small quantity samples?

Yes! We understand the quality test is important and we are glad to make the sample for you. The MOQ is 1 pcs.

#### What colors are available?

Red, black, others as required.

#### Do you have quality control system?

Yes, we have Strict Quality Control System from raw material to the final finished products to customer. The 6S and ERP management systems are rigidly implemented throughout our whole company. Our factory is an ISO9001 and CE certified manufacturer.

#### How do I choose your cylinder?

You can tell me your specifications, and we can choose the best model for you. We also have some regular models for you to choose from. You can also provide the product drawings, sizes, and photographs, and we can design the appropriate cylinder for you according to your requirements.

#### What is the material of the cylinder tube?

Honed steel,precision finished for extended seal life.
